Quick Tip: How to Debug an AS3 Error #1203

In this Quick Tip, we’ll discuss the confusing AS3 error 1203, “no constructor found”, which crops up without provocation and is rather unfortunately worded. We’ll examine the scenario in which it will appear, and how to fix it.

---

Step 1: An Obligatory But Somewhat Useless Description of Error 1203

First, here is the language of the error:

1203: No default constructor found in base class flash.display:BitmapData.

It’s difficult to break this down into plain English. So let’s next move on to a scenario that produces this error.

---

Step 2: A Busted Project

You can find this project in the download package, in the folder “busted“. It consists of the following (which you can use to re-create this project if you prefer a hands-on approach):

1. A FLA named Busted.fla. It is empty, but is linked to the document class described next.

2. A document class named Busted.as. This extends Sprite and simply creates an instance of the class described next, and adds it to the stage.
   The contents of the class are as follows:

       package {
           import flash.display.*;
           public class Busted extends Sprite {
               public function Busted() {
                   var bmp:Bitmap = new Bitmap(new BustedBitmap());
                   addChild(bmp);
               }
           }
       }



   The BustedBitmap class extends BitmapData, and so we use it to feed a Bitmap object, which is then added to the stage.

3. Another class file named BustedBitmap.as. As mentioned previously, this extends BitmapData, and its purpose is to be a BitmapData that automatically supplies itself with some Perlin noise. Its contents are:

       package {
           import flash.display.*;
           public class BustedBitmap extends BitmapData {
               public function BustedBitmap() {
                   perlinNoise(100, 100, 2, 1024, false, false, 7, true);
               }
           }
       }



   So, in the BustedBitmap constructor, we call perlinNoise() and thus we automatically have something interesting in the pixel data, so we can see something right away when displaying on the stage.

Now, go ahead and test the movie. You will get Error 1203, pointed at line 4 of BustedBitmap.as. And line 4 is…

public function BustedBitmap() {

---

Step 3: What’s All This, Then?

So what happened? The big thing to keep in mind is that we’re writing a class that is a subclass of another class (BitmapData in this case). Also keep in mind that when a class is instantiated, the constructor is called as part of the “new” process.

If you do not actually write a constructor, ActionScript will imply one for you. It will look like this:

public function [NameOfClass]() {

}

Where “[NameOfClass]” will match the name of your class.

Similarly, if you write a subclass, and don’t call super() in it, then ActionScript will imply that call for you, as well. It will look like this:

public function [NameOfSubclass]() {
    super();
    // Other explicit code in subclass constructor
}

Note that it happens on the first line, and is simply a call to super with no arguments.

Finally, we get to the root of the problem. If your subclass omits an explicit call to super, and your superclass’s constructor has required parameters, then your implicit call to super does not supply the required parameters. You’d think that an argument mismatch error could catch this, but consider that since there isn’t any code actually written to make the mismatch, ActionScript can only complain that the lack of a default constructor.

In our example, BustedBitmap extend BitmapData, which has a constructor defined in the documentation as so:

BitmapData(width:int, height:int, transparent:Boolean = true, fillColor:uint = 0xFFFFFFFF)

The first two parameters are required, and we’re not supplying them.

---

Step 4: It’s as Simple As…

The solution is, once you understand the problem, extremely simple. You need to explicitly call the super constructor, at least if there are required parameters. In other words, in our BustedBitmap class, this following highlighted line will fix the problem:

package {
    import flash.display.*;
    public class BustedBitmap extends BitmapData {
        public function BustedBitmap() {
            super(600, 400);
            perlinNoise(100, 100, 2, 1024, false, false, 7, true);
        }
    }
}

And that will do it.

As a teachable moment, I’d like to add that, when extending another class, it’s generally a good idea to include the explicit call to super. Even if there are no parameters at all, required or otherwise (as in Sprite or MovieClip), an explicit call can declare intention and awareness of the nature of the subclass. More practically, explicit calls give you an opportunity to run some code prior to the call to super, which may be helpful in certain situations.

---

Step 5: …And That Is All

Yet another error demystified; the challenge for this one is that the real cause of the error is quite buried. Once you become handy with a shovel, though, the fix is easy enough.

Thanks for reading, and be ready for more debugging tips.

View full post on Activetuts+

Jan 30, 2012 Posted on Jan 30, 2012 in Hints and Tips | 10 comments

Quick Tip: Implementing the Bubble Sort in AS3

In this Quick Tip, I’ll show you how and why the Bubble Sort algorithm works, and how to implement it in AS3. You’ll end up with a class that you can use in any Flash project, for sorting any array.

---

Final Result Preview

Here’s a simple demo of the result of the bubble sort algorithm:

Of course, this SWF doesn’t prove much on its own! Grab the source files and you can edit the input array yourself.

---

Step 1: Creating the BubbleSort Class

As this algorithm will be used more than once, it’s a good idea to create a class for it, so that we can easily use it in any AS3 project:

Set up a basic Flash project, and inside the project folder create a file BubbleSort.as. (We will create a tester file here too, so we can test it.)

If you dont know how to work with classes please check this tutorial: How to Use a Document Class in Flash.

We wont need the constructor, so get rid of it! Your class should look like this:

package
{

	public class BubbleSort
	{

	}

}

---

Step 2: How the Algorithm Works

This algorithm is not the fastest or most efficient method of sorting a series of numbers, but it is the easiest one to understand.

This image sums it up; at every stage, each pair of numbers are compared, starting from the end, and swapped (by means of a “spare” temp variable) if they are in the wrong order.

Once all consecutive pairs have been checked, this guarantees that the number at the start is the largest number in the sequence; we then repeat, checking every pair of numbers apart from the number at the start. Once all consecutive pairs have been checked, we know that the first two numbers in the sequence are in the correct order (they are the largest and second-largest). We keep going until we’ve put every number in the correct order.

It’s called the “bubble sort” because, on each pass through the array, the biggest number “floats” to the top of the array, like a bubble in water.

Lets start writing the code. We’ll call the main function bsort():

package
{

	public class BubbleSort
	{
		public function bsort(arr:Array,sortType:String):Array
		{
			var temp:String;
			if(sortType.toLocaleLowerCase() == "descending")
			{

			}
			else if(sortType.toLocaleLowerCase() == "ascending")
			{

			}
			else
				throw new Error("You have a typo when Calling the bsort() function, please use 'ascending' or 'descending' for sortType!");

			return arr;
		}

	}

}

The function gets two parameters. The first parameter, arr, will be the array to be sorted; the second paramter, sortType will be used to decide if the user wants the array to be sorted in ascending or descending order.

In the function we declare a temp variable which will hold the elements of the array in case we need to swap the two elements. You may wonder why it is not a Number. It’s because our class will be able to handle String arrays too, sorting them alphabetically; we can convert numbers to strings and back again, but we can’t convert strings to numbers and back again, so we use a String for this variable, just to be safe.

We use an if-else block to split our code into two branches, depending on which direction the user wants to sort in. (If the user does not provide a valid choice, the program will fire an error.)

The difference between the code in either branch will be just one character: either < or >.

Let’s write the algorithm. We start with the descending part:

package
{

	public class BubbleSort
	{
		public function bsort(arr:Array,sortType:String):Array
		{
			var temp:String;
			if(sortType.toLocaleLowerCase() == "descending")
			{
				for(var i:uint=0; i < arr.length; i++)
				{
					for(var j:uint=arr.length-1; j > i; j--)
					{

					}
				}
			}
			else if(sortType.toLocaleLowerCase() == "ascending")
			{

			}
			else
				throw new Error("You have a typo when Calling the bsort() function, please use 'ascending' or 'descending' for sortType!");

			return arr;
		}

	}

}

As you can see, we’re using nested for loops. One goes from the first element to the last element of the array; the other goes backwards.

Let’s inspect the inner “j” loop first. As the earlier diagram shows, we begin by comparing the last two elements of the array, which are arr[j-1] and arr[j] (in the first iteration). If arr[j-1] is less than arr[j] they need to be swapped.

In either case we subtract one from j (through the “j--” call in line 131), which changes which pair of numbers will be compared on the next loop.

j starts at a value of arr.length-1, and ends with a value of 1, meaning that the inner for loop checks every consecutive pair, starting with the last pair (where j equals arr.length-1) and ending with the first pair (where j equals 1).

Now let’s look at the outer “i” loop. Once all the pairs have been checked and swapped as necessary, i is increased (through the “i++” call in line 129). This means that, the next time round, j will start at arr.length-1 again, but end at 2 this time – meaning that the first pair in the sequence will not be checked or swapped. This is exactly what we want, since we know that the first number is in the correct position.

As it goes on, eventually there will be only two elements that need to be checked in the inner loop. Once they’re done, we know we’ve sorted the array!

Here’s what that looks like in code:

				for(var i:uint=0; i<arr.length;i++)
				{
					for(var j:uint=arr.length-1; j > i; j--)
					{
						if (arr[j-1] < arr[j])
						{
							temp = arr[j-1];
							arr[j-1] = arr[j];
							arr[j] = temp;
						}
					}
				}

And the algorithm is ready!

Now we can use the same logic to create the ascending sort:

We need only to change the comparison operator in the if block of the inner loop:

package
{

	public class BubbleSort
	{

		public function bsort(arr:Array,sortType:String):Array
		{
			var temp:String;
			if(sortType.toLocaleLowerCase() == "descending")
			{
				for(var i:uint=0; i<arr.length;i++)
				{
					for(var j:uint=arr.length-1; j > i; j--)
					{
						if (arr[j-1] < arr[j])
						{
							temp = arr[j-1];
							arr[j-1] = arr[j];
							arr[j] = temp;
						}
					}
				}
			}
			else if(sortType.toLocaleLowerCase() == "ascending")
			{
				for(var k:uint=0; k<arr.length;k++)
				{
					for(var l:uint=arr.length-1; l > k; l--)
					{
						if (arr[l-1] > arr[l])
						{
							temp = arr[l-1];
							arr[l-1] = arr[l];
							arr[l] = temp;
						}
					}
				}
			}
			else
			{
				throw new Error("You have a typo when Calling the bsort() function, please use 'ascending' or 'descending' for sortType!");
			}

			return arr;
		}
	}

}

---

Step 3: Creating the Tester Application

Create a new flash file, tester.fla, in the same folder as BubbleSort.as. Create two dynamic text fields, name one input_arr and the other one output_arr.

After creating the appearance, we must create and link the document class.

Create a file Tester.as and link this to tester.fla

Now we can finally use our class in the Tester.as:

package
{
	import BubbleSort;
	import flash.display.MovieClip;

	public class Tester extends MovieClip {

		private var bs:BubbleSort = new BubbleSort();

		public function Tester() {
			var ar:Array = [5,7,9,8,1,3,6,2,4,5,0];
			input_arr.text = ar.toString();
			ar = bs.bsort(ar,"descending");
			output_arr.text = ar.toString();
		}
	}
}

In this line, we call the bsort() function of our variable bs (which is an instance of BubbleSort):

ar = bs.bsort(ar,"ascending");

This function returns an array, so we can assign this as the new value of our original input array.

Save everything and try your work out.

---

Conclusion

In this tutorial we created a function to help us sort an Array. We could improve the efficiency; for more on that, you can read Wikipedia – Bubble Sort

If you really wish to see how fast this algorithm is compared to the other options (like quicksort), take a look at sorting-algorithms.com.
